Haifly Plastic Machine Co.,Ltd. Localed in Ningbo City, Near Shanghai. It is a manufacturer Specialized for Injection moulding machineinjection mould and offer auxiliary equipment also
 Injection moulding machine range: clamping force from 50tons to1000tons, infaction weight from 13356g.Machine series:
A) Standard Injection Molding
B) PVC injection molding machine;
C) PET injection molding machine;
D) Double Color injection machine;
E) Full hydraulic injection molding ;
F) All electric injection moulding machine; full injection molding machine;
G) Energy saving injection moulding machine :
    (a) Variable Displacement pump injection machine (b) Servo motor injection molding
 All our machine use famous brand component,say:Yuken /Vickers/Northman valve,Yuken/Vickers Pump,Omron/Schneider Switch,Porchesion computer,Valqua Seal;HNC Proportional Valve;Moot Proportinal liner

 Haifly Injection Molding Machine Features:
Low noise electric motor;
Low noise pump (gear pump);
Fast response of 0.05 seconds;
Low water consumption (because the system will not be pressurized into phases of the process);
Low maintenance electrical and hydraulic;
Power consumption reduction of up to 80% depending on the cycle, the machine begins to save energy when the the cycle exceeds 18seg;
Accuracy in movement;
Output control sensor for  flow and pressure;
Servo Motor;
Frequency inverter.

Haifly Injection Molding Machine Control System:

The Injectiond machine is controlled via Micro Processor with PLC Techmation Taiwan  brand.

 Using the A63versions with display of 12 ", with touch screen  in Portuguese language with easy operation with the following characteristics:

- Temperature Control type "PID"

- Weekly Schedule

- Control to maintain low temperature, when the injection is stopped

- Internal storage memory to 50 molds.

- Fault diagnostics with alarm messages

- Low power consumption

- Digital Back Presure, via PLC

- Oil Filter with By-Pass

- Command Control Panel Shielded against Magnetic Interference

- Colorful Digital Display

- Signs and Warning Signs in Portuguese

- Alarms malfunction on display

- Digital Counters for parts and packages selected ( predefined number per boxes)

- Programming heating for the seven days of the week

- Control Charts for operations

- Monitoring of process and quality control

- Monitoring of stops (alarms)

- Pre-arrangement for printer

- Pre-arrangement for process management

- Alarms filter suction oil

- Alarm electric motor protection

- High speed set

- Blocking of data access and display with removable key

Closure Unit:

- New compact design

Hydraulics:

- Basic Components manufactured by Vickers, and Rex Roth or Yuken



- Automatic Filter Oil
- Pump with low-noise

- Hydraulic Motors are  used following the characteristic of each model and can be from the brands

Eaton, Staff, Dinamicoil, Calzoni, TOKIMEC, Vickers, Yuken and Hagglud

- Oil Temperature Alarm

- Automatic and adjustable Centralized lubrication

- Directional valves that ensure the accuracy and process stability.

- Additional DaikinandTries Valve (Japanese)

- NOK Seals (American)

- Hoses Manulli (Italian)

Haifly Injection Molding Machine Injection unit:

- Injection unit made of steel and hardness  above 1100 HC

- Screw and Barrel in bimetallic  and diverse screw profiles (custom)

- Injection within 06 (six) steps (pressure, position and time)

- Holding Presure  within 05 (five) steps (speed and time pressure)

- Back Pressure Control

- Dosing of plastic material in 02 (two) steps (speeds, pressures and position)

- Automatic Programming Purge (auto purge)

- Protection against Cooling screw

- Injection volume control function

- Self Diagnosis

- Rotation of the screw programmable in 03 (three) steps

General Features and Additional Items:

- Built according to international standards and Euromap NBR

- Linear potentiometric (Injection, Puller and Lock)

- 03 (three) three-pole sockets for connecting peripherals

- Pre-arrangement for Robots

- Mechanical, Electrical and Hydraulic devices in accordance with Brazilian security standards NR-12

- Security System against whipping hoses

- Oil Collectors

- Injection system driven by two cylinders

- Injection unit  with lateral movement for maintenance and exchange of screw and barrel

- Automatic  adjustment of molds height

- Electrical safety switch

- Clamping set  for fixing the molds

- Vibra Stop set

- Set of emergency spare parts (resistors, tip, rings and thermocouples)

- Tool set  for small repairs and specific additional tools for the machine

- Manyfold  for water distribution

Haifly Injection Molding Machine Warranty: For a period of 24 (twenty four) months which covers the replacement and / or repair

any component that has a manufacturing defect and / or material.
